S-25

 O=C(N(C(CCCCCCCCCCCC)CCCCCCCCCCCC)C7=O)C2=CC=C(C4=CC=C6C5=C(C(N(C(CCCCCCCCCCCC)CCCCCCCCCCCC)C6=O)=O)C=CC3=C45)C1=C3C=CC7=C12

N,N‘-Bis(1-docecyltridecyl)-3,4:9,10-perylenebis(dicarboximide); 2,9-bis-(1-dodecyltridecyl)anthra[2,1,9-def;6,5,10-d‘e‘f‘]diisoquinoline-1,3,8,10(2H,9H)-tetraone; 2,9-bis-(13-pentacosanyl)anthra[2,1,9-def;6,5,10-d‘e‘f‘]diisoquinoline-1,3,8,10(2H,9H)-tetraone, RN 139260-32-5:
M.p. 74.5C, orange crystals. UV (CHCl3): λmax (ε) = 458 nm (18830), 489 (50790), 525 (84490). C74H110N2O4 (1090.9) calcd. C 81.42, H 10.16, N 2.57; found C 81.51, H 10.09, N 2.76.


References, RN 139260-32-5:

*1. Langhals, H.; Demmig, S.; Potrawa, T. ‘The relation between packing effects and solid state fluorescence of dyes’, J. Prakt. Chem. (Leipzig) 1991, 333, 733-748.

2. Langhals, H.; Demmig, S. ‘Perylene dyes and their use as permanent toner in electrophotography and laser printing’, Ger. Offen. 1991, DE 4007618 A1 19910912.

3. Schott, H.; Von Cunow, D.; Langhals, H. ‘Labeling of liposomes with intercalating perylene fluorescent dyes’, Biochim. Biophys. Acta, Biomembranes 1992, 1110, 151-157.

4. Robinson, M. R.; Furuta, P.; Lazarev, P. I. ‘Coiled capacitor comprising a layer of energy storage material’, PCT Int. Appl. 2016, WO 2016210349 A1 20161229.

5. Robinson, M. R.; Furuta, P.; Lazarev, P. I. ‘Coiled capacitor comprising a layer of energy storage material’, U.S. Pat. Appl. Publ. 2016, US 20160379757 A1 20161229.
